Fiber optic cable inlet and outlet holes

1 TJ-T01 adapter Φ 6-18 mm straight through optical cable

2 TJ-F01 adaptations Φ 5-12mm branching optical cable

16 SC/APC outdoor adapters

Installation method

Wall hanging

Application Scenario

mine

Dimensions (height x width x depth, in millimeters)

394*208*142

Shell material

PP+GF

Colour

black

Protection level

IP68

Impact resistance level

IK09

Flame retardant grade

FV2

Antistatic

Meet GB3836.1

RoHS

satisfy

Sealing method

mechanical

adapter type

SC/APC outdoor adapter

Wiring capacity (in cores)

16

Fusion capacity (in cores)

96

Type of fusion disc

RJP-12-1

Maximum number of fusion discs

8

Single disc fusion capacity (unit: core)

12

Tail fiber type

16SC/APC tail fibers, length 1m, sheath madeof  LSZH material, and optical fiber made of G.657A1 fiber
