CNT-16G terminal box 16 core distribution box

* Total enclosed structure.

* Material: PC+ABS, wet-proof、water-proof 、dust-proof 、anti-aging, protection level up to IP65。

* Clamping for feeder cable and drop cable, fiber splicing, fixation, storage, distribution...etc all in one.

* Cable, pigtails, patch cords are running through own path without disturbing each other, cassette type SC adaptor installation, easy maintenance.

* Distribution panel can be flipped up, feeder cable can be placed in a cup-joint way, easy for maintenance and installation.

* Cabinet can be installed by the way of wall-mounted or poled-mounted, suitable for both indoor and outdoor uses.

Model No.	CNT-16G
Dimension(LXWXH) mm	293x219x84
Installation	Wall mounting(Indoor/Outdoor) Pole mounting
Protection Level	IP65
Cable Entries	Supporting Uncut
Max Cable Diameter	Max Input=⌀18mm Max Output= ⌀4.6mm
No. Of Adapters & Splitters	16pcs SC SX, 16pcs LC DX, 1pcs 1x16 plc or 2pcs 1x8 plc
Packing Information	G.W.:16.8kg QTY.:10 pcs/Carton MEAS.:51x34x69cm
